Ovonic 11.1 V 35C 2200mAh 3S T Plug Lipo Battery with D15 Dual 1.2A 1-3S LiPo Charger
Save 5%
Original Price
$82.99 AUD
Current Price
$78.99 AUD
Description
Why choose us
D15 Charger Key Features:
- 15W*2 Dual Channel: Charge two LiPo batteries simultaneously with 15W per channel for fast and efficient charging.
- Error-detecting: Built-in technology ensures your LiPo batteries are charged safely by detecting abnormalities.
- 1.2A Charging Current: Compatible with a wide range of 1S to 3S LiPo batteries, ideal for all your RC vehicle and drone charging needs.
- Plug-and-Play: User-friendly operation allows easy charging of your LiPo batteries, with automatic shutdown when not in use.
- Compact and Portable: Lightweight and compact design, ideal for taking it wherever your adventures take you.
Specification of Ovonic D15 Dual Lipo Charger:
| Product Model | D15 |
| Input Voltage | 100-240V/AC |
| Output Current | 100-1200mA |
| Display | 1 Green/Red LEDS |
| Dimensions | 100*80*34.5mm |
| Net Weight | Approx. 165g |
| Power | 15W*2 |
| Current | Maximum Current 1.2A (Average Current 0.8A) |
| Full Charge Voltage | Active balancing, 5%+21mV (4.2*5/1000=21mV) |
| Compatible Batteries | 1s-3s LiPo, 3.7V-11.1V |
| Battery Error Detection | Voltage differential >350mV, Voltage < 2.5V, Voltage > 4.25V, Cell damage, Poor contact |
| Charge Time Test | 2200mAh 3S battery: 2-hour full charge time (charges at 18.33mAh per minute), 7200mAh 2S battery: 6.5-hour full charge time (charges at 18.46mAh per minute) |
| Blinking Logic | Green Flashing three times - Power Connected, Red Flashing - Charging, Solid Green Light - Full Charged, Solid Red Light - Error Warning |
| Power Management | Yes (to achieve better balance, there is basically no voltage difference when fully charged) |
| Safety Test | AC and DC withstand voltage test, ground resistance test, insulation resistance test, leakage current test |
Spec of 2200mAh 3S LiPo
- Chemistry：Li-Polymer(LiPo)
- Configuration：3S1P
- Voltage(V)：11.1V
- Capacity(mAh)：2200mAh
- Discharge Rate: 35C
- Max Burst Discharge Rate: 70C
- Length(dev.5mm) : 75mm
- Width(dev.2mm) : 34mm
- Height(dev.2mm) : 26mm
- Net Weight(dev.20g)：140g for one pack
- Connector Type: T Plug
- Charge Plug: JST-XHR
Compatible with:
Ovonic 2200mAh 3S 35C lipo battery can be used on many types of RC model like 1/14,1/16 scale RC Cars, Trucks, much as extra battery clip perfectly fits HYPER GO 1/16 RC CAR or HYPER GO 1/14 RC CAR ; for other rc hobby: park flyer plane, Heli and airsoft, boat etc.
Package Content:
2X Ovonic 11.1V 35C 2200mAh 3S LiPo Battery with T Plug
2X Ovonic 11.1V 35C 2200mAh 3S LiPo Battery with T Plug
1X Ovonic D15 1S-3S Lipo Balance Charger with AC Input Cable
